1U - 5U Rugged Servers and Workstations

Trenton Rugged™ servers and workstations are built in-house to guarantee reliability, offer hardened security, and exceed the most complex specs & requirements in the harshest conditions.

Whether you're looking for a military-grade or industrial computer, our long-life, ruggedized 19" standard rackmount computers answer the call of duty daily on sea, land, air, or space across critical applications and programs worldwide.

Request Pricing  E-mail Us  Give us a call

1000 Series Rugged Servers

Certifications
MIL-STD-810 | MIL-STD-461 | CE | FCC
1U Rugged Servers Product Listing
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5 TB DDR4-2933 across 8 ECC RDIMMs (6 channels)
Slots: Up to 2 PCIe Gen3 Slots
Storage: Two front-access/hot-swap and two internal SATA 6 Gb/s drives up to four optional M.2 drives
Size: 1U servers | 19" deep


*Option with multiple processor boards in one rugged server pictured above

Request Pricing

View Options

Call to Action

2000 Series Rugged Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
2U Rugged Servers
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5 TB DDR4-2933 across 8 or 12 ECC RDIMMs (6 channels)
Slots: Up to 7 PCIe Gen3 Slots
Storage: Up to six SATA 6 Gb/s drives and one SlimLine Optical drive
Size: 2U servers | 18" - 18.2" deep



Request Pricing

Learn More

Call to Action

3000 Series Rugged Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
3U Rugged Servers Product Listings
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5 TB DDR4-2933 across 12 ECC RDIMMs (6 channels)
Slots: Up to 7 PCIe Gen3 Slots
Drives: Up to nine SATA 6 Gb/s drives and one SlimLine Optical drive
Size: 3U servers | 20" deep



Request Pricing

View Options

Call to Action

4000 Series Rugged Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
4U Rugged Servers
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5 TB DDR4-2933 across 8 or 12 ECC RDIMMs (6 channels)
Slots: Up to 18 PCIe Slots
Storage: Up to 16 SATA 6 Gb/s drives and one SlimLine Optical drive
Size: 4U servers | 20" - 26" deep



Request Pricing

View Options

Call to Action

5000 Series Rugged Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
5U Rugged Servers Product Listing
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5TB DDR4-2933 across 8 ECC RDIMMs (6 channels)
Slots: Up 18 PCIe Gen3 Slots
Storage: Up to 48 front-access/hot-swap SATA 6 Gb/s drives and 4 internal, fixed 2.5" 6 Gb/s SATA drives, and up to two SlimLine Optical drives
Size: 5U servers | 19.2" - 24.5" deep



Request Pricing

Get More Info

Call to Action

1000 Series Rugged Workstations

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
1000 Series Worksations
CPU: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Memory: Up to 64GB DDR4-2400 across 4 ECC DIMMs (2 Channels)
Slots: Up to 2 PCIe slots
Storage: Up to two front-access / hot-swap SATA 6 Gb/s drives, up to two internal SATA 6 Gb/s drives, and up to four optional M.2 drives
Size: 1U rackmount | 19" deep


*Option with multiple processor boards in one rugged server pictured above

Request Pricing

Get More Info

Call to Action

2000 Series Rugged Workstations

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
2U Chassis Brighter
CPU: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Memory: Up to 64GB DDR4-2400 across 4 ECC DIMMs (2 Channels)
Slots: Up to 4 PCIe slots + 1 PCI-X slot for legacy support
Storage: Up to six SATA 6 Gb/s drives & one SlimLine DVD Drive
Size: 2U rackmount | 18" deep



Request Pricing

View Options

Call to Action

4000 Series Rugged Workstations

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
4U Chassis
CPU: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Memory: Up to 64GB DDR4-2400 across 4 ECC DIMMs (2 Channels)
Slots: Up to 12 PCIe slots
Storage: Up to 16 SATA 6 Gb/s drives & one SlimLine DVD Drive
Size: 4U rackmount | 16.5" - 26" deep



Request Pricing

View Options

Call to Action

5000 Series Rugged Workstations

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
5U Rugged Workstations
CPU: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Memory: Up to 64GB DDR4-2400 across 4 ECC DIMMs (2 Channels)
Slots: Up to 18 PCIe slots
Storage: 48 front-access/hot-swap SATA 6 Gb/s drives and four internal, fixed 2.5" 6 Gb/s SATA drives
Depth: 5U rackmount | 18" - 24.5" deep



Request Pricing

Get More Info

Call to Action

1000 Series Rugged Blade Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
1000 Series Blade Servers a
# of Server Blades: 1 - 2
Blade Option 1: Dual Intel® Xeon® Scalable Performance Silver 4100, Gold 5100 & 6100 Series CPUs
Blade Option 2: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Slots: Up to two PCIe Gen3 Slots
Drives: Up to two SATA 6 Gb/s drives & up to four internal M.2 NVMe drives
Power Supply: 1200W Removable
Size: 1U blade servers | 19" deep


*Ready to add modularity to any rugged military or industrial computer.

Request Pricing

View Options

Call to Action

2000 Series Rugged Blade Servers

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
MBS2000a
# of Server Blades: 2 - 4
Blade Option 1: Dual Intel® Xeon® Scalable Performance Silver 4100, Gold 5100 & 6100 Series CPUs
Blade Option 2: 7th Gen Intel® Core™ i3, i5, i7 or Intel® Xeon® E3 v6
Slots: Up to 4 PCIe Gen3 Slots
Drives: Up to two front-access / hot-swap SATA 6 Gb/s drives, up to four internal SATA 6 Gb/s drives, and up to four internal M.2 NVMe drives
Power Supply: 1200W Redundant
Size: 2U blade servers | 19" - 25.75" deep



Request Pricing

Get More Info

Call to Action

JBOD/JBOF Rugged Storage

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
JBOD Server
CPU: 32 lanes of PCIe uplink to a rugged server
PCIe: Direct end-to-end PCIe without translation
Transfer Rate: Up to 27 GB/s read/write speeds
Storage: 24 NVMe U.2 Drives
Size: 2U JBOD | 16.2" deep


*A JBOF / JBOD server that communicates at 27 GB/s read & write speeds with up to two hosts using native PCIe NVMe.

Request Pricing

Explore

Call to Action

5000 Series Rugged Storage Systems

Certifications

MIL-STD-810 | MIL-STD-461 | CE | FCC
5000 Series Rugged Storage Systems
CPU: Dual Intel® Xeon® Scalable Performance
Memory: Up to 1.5 TB DDR4-2933 across 8 ECC RDIMMs (6 channels)
PCIe: Up to 18 PCIe slots
Drives: 48 front-access/hot-swap SATA 6 Gb/s drives and 4 internal, fixed 2.5" 6Gb/s SATA drives
Size: 5U storage servers | 24.5" deep



Request Pricing

Learn More

Call to Action

Rugged Mini PC

A Mini PC that fits rugged applications

Small form factor yet insane performance
Coming Soon

Trenton Rugged™ goes Mini PC. The small footprint form factor makes it perfect for applications that are SWaP-conscious and work in rugged environments. Don't forget to sign-up for updates and we'll keep you posted on the developments of this project.

Learn More

COM Express® Type 7

Based on Intel® Xeon® D Family Processors

Ideal for a wide range of programs and applications
Coming Soon

Unbelievably light. Undeniably powerful. Experience true ruggedness in a small COM Express® form factor. Don't forget to subscribe and we'll send you periodic updates on this project.

Learn More

Learn about our

Loaner Program →

*Any product. Free for 45 days.

Take a look at our

Rugged Components →

Let's Build Your Rugged Computer

It takes less than a minute!

Send Us Your Specs
