Top Five Challenges Posed by Traditional RAID, and How They Can Be Solved
by Christopher Trick on Oct 5, 2023 12:25:16 PM
Traditional hardware- and software-based based RAID poses many technical and performance issues that hinder the capabilities of NVMe SSDs, which, in turn, limits the ability of computing systems to quickly store and retrieve large amount of critical data.
Trenton Systems and Graid Technology Inc. have partnered to create a fully integrated, end-to-end solution that unlocks the full potential of NVMe SSDs to maximize performance on premises and at the edge.
What is RAID (Redundant Array of Independent Disks)?
RAID, which stands for Redundant Array of Independent Disks is a technology used in data storage to improve performance, reliability, and/or both.
It involves using multiple physical hard drives (or SSDs) together in various configurations to achieve specific goals, such as redundancy, increased speed, or a combination of both.
The choice of RAID level depends on the specific needs of the storage system, such as performance, data protection, and available hardware. RAID arrays are commonly used in enterprise environments to ensure data availability and reliability, but they can also be employed in consumer-grade storage solutions for improved performance and data security.
(To learn more about the different RAID configurations, click here.)
What are the top five challenges posed by traditional RAID?
Hardware-based RAID
Hardware-based RAID (Redundant Array of Independent Disks) systems have been widely used for data storage and redundancy. However, they come with several challenges, including:
- Cost: Hardware-based RAID solutions typically involve specialized RAID controllers, which can be expensive. These controllers are often proprietary and require additional hardware components, contributing to higher overall system costs.
- Scalability: Expanding a hardware-based RAID array can be challenging. Adding more disks often means purchasing additional RAID controllers and potentially even migrating data to a new RAID level or configuration. This scalability limitation can be a significant hindrance in dynamic environments where storage needs can quickly change.
- Performance Bottlenecks:
- CPU Utilization: Hardware-based RAID controllers offload many of the complex RAID calculations (e.g., parity calculations in RAID 5 and RAID 6) onto the system's CPU. While modern CPUs are powerful and capable, these calculations can still consume a substantial portion of CPU resources, especially when handling a high volume of I/O operations. This CPU utilization can limit the overall system performance, particularly in scenarios with heavy disk activity.
- I/O Bottlenecks: Hardware-based RAID controllers can become performance bottlenecks, especially when handling high I/O workloads. All data traffic must pass through the controller, which can lead to contention and reduced performance. Even the fastest hardware RAID products cannot match the aggregate performance of solid-state drives (SSDs). The resulting performance bottleneck is unavoidable and worsens when using SSDs with PCI Express (PCIe) and NVM Express (NVMe) technologies.
- Write Penalty: Many RAID configurations, such as RAID 5 and RAID 6, suffer from a “write penalty” because they require multiple disk operations to write data. This can significantly impact write-intensive workloads.
- Rebuild Times: When a disk in a RAID array fails, the process of rebuilding data onto a replacement disk can take a long time. During this rebuild process, the system’s performance may be degraded, and there is an increased risk of another disk failure (resulting in data loss for some RAID levels).
- Complexity: Setting up and managing traditional hardware-based RAID can be complex. Configuration options, such as choosing the right RAID level, stripe size, and hot spare policies, require expertise. RAID management interfaces are often vendor-specific and may not be intuitive for all administrators.
- Vendor Lock-In: Hardware-based RAID solutions are often tied to specific vendors and hardware platforms. This can create vendor lock-in, making it difficult and costly to switch to a different storage solution or migrate data to a different platform in the future.
Hardware RAID creates a performance bottleneck due to lane limitations
Software-based RAID
Software-based RAID offers a cost-effective way to achieve data redundancy and performance improvements using standard hardware. However, it also comes with its own set of challenges and limitations, including:
- Performance Overhead: Software-based RAID relies on the host CPU to manage the RAID array. This can result in a significant performance overhead, especially for complex RAID levels like RAID 5 and RAID 6. The CPU has to handle data striping, parity calculations, and other RAID functions, which can impact the overall system performance.
- Limited RAID Levels: Software-based RAID typically supports a limited set of RAID levels compared to hardware RAID controllers. It may not offer advanced RAID levels like RAID 10 or RAID 50, limiting the flexibility and performance optimization options available.
- Scalability: Expanding or reconfiguring a software-based RAID array can be more challenging than with hardware-based RAID. Adding new drives or changing the RAID level often requires migrating data and can be error-prone, potentially leading to data loss.
- Dependency on the Operating System: Software-based RAID is closely tied to the operating system. If the OS experiences issues or becomes corrupted, it can affect the integrity of the RAID array. Additionally, software RAID may not be available or fully functional on all operating systems.
- Limited Performance in High-Load Environments: In high-demand environments with heavy I/O loads, software-based RAID can struggle to keep up with the demand. Hardware-based RAID controllers often have dedicated processors and cache memory to handle such loads more efficiently.
Software RAID competes with your operating system and applications, taxing the CPU
It is important to note that software-based RAID can be a viable solution for certain scenarios, especially when cost savings are a priority or when using a RAID configuration for non-mission-critical applications.
However, for high-performance and mission-critical applications, hardware-based RAID controllers or even hybrid solutions may be a better choice to address these challenges effectively.
How can these problems be fixed?
To address some of these challenges, many organizations have started to explore GPU-based software RAID solutions or software-defined storage (SDS) options. These approaches can provide greater flexibility, scalability, and cost-effectiveness while mitigating some of the performance bottlenecks associated with traditional hardware-based RAID.
Additionally, advancements in hardware technology, such as faster storage interfaces (e.g., NVMe) and more powerful CPUs, have allowed for better RAID performance in modern systems.
Introducing SupremeRAIDTM
Graid Technology Inc.’s SupremeRAIDTM is a software-defined RAID solution deployed on a GPU to maximize NVMe SSD performance without overloading a CPU.
Unlike traditional hardware- and software-based RAID, data travels directly from the CPU to storage, minimizing performance bottlenecks while increasing scalability, improving flexibility, and reducing total cost of ownership.
It combines two powerful technologies — software-defined storage and GPU acceleration — to create an innovative solution ideal for NVMe SSD data protection. The result is better RAID-protected storage with the same PCIe NVMe SSDs.
SupremeRAID™ Value vs. Traditional RAID
Instant Return on Investment: SupremeRAID™ exceeds performance requirements with fewer SSDs. The amount of money saved more than pays for the SupremeRAID™ solution.
Non-blocking Performance: SupremeRAID™ leaves SSDs connected to the server board, eliminating the unavoidable bottlenecks that exist when SSDs connect to add-in cards.
Higher System Efficiency: SupremeRAID™ needs minimal resources to protect data, leaving more CPU cores for applications and more PCIe bandwidth for data.
Better Storage Availability: SupremeRAID™ performance remains little changed during SSD failures, protecting service levels for databases, applications, and users.
Faster RAID Recovery: SupremeRAID™ rebuilds data at multiple TBs per hour with a low impact on performance, enabling recovery to begin anytime and complete quickly.
Fast and Easy Installation: SupremeRAID™ installation couldn’t be easier. Just plug it in and go. Competitors’ hardware RAID product installs can require reconfiguring drive bays, replacing drive cables, and changing power connections.
Future-proof Solution: SupremeRAID™ supports PCI Gen 3, 4, and 5 servers and SSDs with one solution. Hardware RAID competitors replaced old Gen 3 products with new Gen 4 ones, but none of their products are available with Gen 5 support.
How SupremeRAID™ Wins Over Traditional RAID
Features |
Benefits |
Advantages |
Record-setting RAID storage performance |
Scale up to 28M IOPS and 260GB/s throughput |
Use more of your SSD’s performance while protecting data |
Modern software-defined storage |
Relies on flexible software to deliver functionality |
Adds and improves features with every software release |
GPU add-in card for RAID acceleration |
Offloads RAID computations from the system’s CPU |
Frees-up CPU cores to process database and app workloads |
PCIe Gen 3, 4, and 5 support today |
Backward and forward SSD and system compatibility |
Supports future tech refreshes using the same RAID solution |
Connect SSDs using NVMe and NVMeoF |
Use internal and external direct-attached SSDs |
Expands storage beyond the limits of server SSD bays |
Scale RAID storage from 2 to 32 SSDs |
Consolidate system data protection using one RAID solution |
Avoids having to use two or more of the same RAID solution |
No battery backups modules |
High performance without volatile caching & batteries |
No battery backup modules to purchase, monitor and replace |
Same solution for Linux and Windows |
Standardize on one RAID solution across multiple data centers |
Simplify system design, management, and administration |
Where does Trenton Systems come into play?
Trenton Systems provides cybersecure, USA-made, COTS hardware with the latest high-performance computing technologies—including next-gen PCIe, CPUs, GPUs, and NVMe SSDs —that can unleash the full potential of SupremeRAIDTM to quicky process, analyze, store, retrieve, and transfer large amounts of critical intelligence in seconds.
In partnership with Graid Technology Inc., we deliver end-to-end, turnkey solutions with all necessary hardware and software fully integrated before ever reaching a customer and/or end user, thus enhancing out-of-box experience.
This, in turn, equips defense and enterprise personnel with readily-deployable systems for a wide range of applications and services.
We work with customers in a consultative relationship to craft systems and solutions per their most complex technical, performance, and environmental requirements.
Final thoughts
RAID technology plays a crucial role in data storage, offering a variety of configurations to meet specific needs. Traditional hardware-based RAID and software-based RAID both have their challenges, including cost, scalability, performance bottlenecks, complexity, and vendor lock-in.
To address these issues, organizations are exploring GPU-based software RAID and software-defined storage options, taking advantage of advancements in hardware technology.
One innovative solution in this space is SupremeRAID™ by Graid Technology Inc. This software-defined RAID solution deployed on a GPU maximizes NVMe SSD performance while minimizing CPU overload, offering benefits such as instant return on investment, non-blocking performance, higher system efficiency, and faster RAID recovery. It is a future-proof solution that supports a wide range of SSDs and server generations.
Trenton Systems, in partnership with Graid Technology Inc., provides the hardware necessary to fully harness the potential of SupremeRAID™. Their cybersecure, USA-made COTS hardware, equipped with the latest high-performance computing technologies, ensures that SupremeRAID™ can process, store, and retrieve critical data rapidly. Together, this offers end-to-end, turnkey solutions to ensure rapid deployment for defense and enterprise applications.
As technology continues to evolve, solutions like SupremeRAID™ and the support provided by Trenton Systems offer a path toward more efficient and flexible data storage and protection, meeting the demands of modern computing environments.
Embracing these innovations can lead to improved data management and storage capabilities for various industries, paving the way for more resilient and high-performance systems in the ever-evolving world of technology.
